Xuzhou Tianyu Gas Power Generation Co., Ltd
Application of steam pipelines

MG2600 Temperature Transmitter + MG2110 Temperature Sensor

● Total Length L*I=180*30mm,PT100,3-wire
● Thread of sensor-housing：M30*1.5
● Straight thermowell，thermowell diameter 16mm SS304
● Process connection：M27*2
● Housing material：Cast aluminum
● Signal output 4~20mA HART LCD display
● Cable entry：1/2"NPT(F)
● Explosion proof：Exd IIC T6
● Ingress protection：IP66，accuracy 0.1%
