The MG5600MV Series Multi Parameter Transmitter is an intelligent Flow/Differential Pressure/Pressure Transmitter produced using advanced double beam suspended MEMS monocrystalline silicon sensors. Featuring internationally leading ultra-high overpressure performance and high precision, the circuit adopts redundant connections and a fully plug-in anti loosening module design. The sensor membrane box is embedded with a dedicated signal processing circuit to achieve personalized storage for pressure and temperature compensation. The circuit modules can be interchanged freely without the need for recalibration, providing high-precision and reliable pressure measurement in high static pressure and high temperature ranges, and converting it into 4-20mADC and HART signal output. Display and configuration operations can be remotely performed through the three buttons on the panel, handheld programmer, upper computer software, and mobile app. Integrated differential pressure/pressure/temperature measurement module with multiple throttling device databases, realizing the functions of three (differential pressure/static pressure/temperature) on-site transmitters and one flow integrator, greatly saving procurement and installation costs, improving system reliability and measurement accuracy.

Standard primary components;

High reliability, high precision, and wide range down ratio;

Stable performance, budget friendly, and long service life;

Flexible installation modes;

Liquid, gas, steam can all be measured;

It can be matched with an integrated Mega-tek Multi-Variable Transmitter, which can achieve dynamic online automatic temperature and pressure compensation, and has advanced self diagnostic function.
