Conductivity meter (hereinafter referred to as the instrument) is used to monitor and control the conductivity value and temperature in aqueous solution. Widely used in power plants, thermal power plants, petrochemicals, metallurgy, paper industry, light industry electronics, environmental water treatment and other fields. Such as power plant cooling water, make-up water, saturated water, condensate water, and boiler water; Monitoring and control of water production equipment such as ion exchange, reverse osmosis EDL, and seawater distillation, as well as the quality of raw and produced water.

This series of instruments is an industrial instrument with optimized design and the use of high-quality chip components with surface mount technology; Equipped with a microprocessor, intelligent networking, and menu based operation; Equipped with functions such as isolated output current, relay output, and communication interface; Configure various conductive electrodes for online continuous measurement and control.

Intelligent type: using a single-chip microprocessor to complete conductivity measurement, temperature measurement, and automatic temperature compensation, etc;

Human computer dialogue interface: menu operation structure, users can operate according to the prompts on the screen;

Networked: capable of remote transmission, monitoring, and control;

Isolation output current: software selects 0-10mA or 4-20mA output;

Measurement range: The upper and lower limit parameters corresponding to the output current can be freely set;

The upper and lower limit over limit alarms can be set arbitrarily, and the over limit will flash to indicate the measurement status;

Two sets of relay control, adjustable hysteresis, can be connected to external control devices such as metering pumps and solenoid valves, and implement self operated dosing control;

Self set password, users can set or modify their own password to prevent unauthorized personnel from entering and causing misoperation;

We can help you retrieve your forgotten instrument password and provide users with contact information for technical consultation and after-sales service;

Capable of calibrating electrodes using standard solutions; Correction functions such as measurement errors;

According to the user's order statement, RS485//RS232 communication interface (communication protocol CD provided) can be provided;

According to the user's order statement, we can provide: 24VDC power supply;

According to the user's project requirements for export abroad, the ordering statement can provide: English version including software menu, operation panel, manual, etc. of the instrument.
