Online turbidity meter (hereinafter referred to as turbidity meter) is a water quality online monitoring instrument with a microprocessor. The online turbidity meter is an industrial online monitoring instrument designed to measure the inlet and outlet turbidity of municipal sewage, industrial wastewater treatment processes, and water plants.

Working principle: The working principle of turbidity analysis instrument is based on scattered light method. The light wave sent by the infrared sensor transmitter is absorbed, reflected and scattered by the measured object during transmission, and only a small part of the light can be irradiated onto the receiver. The transmittance of the transmitted light is proportional to the concentration of the measured suspended object. The turbidity concentration is calculated by measuring the transmittance of the transmitted light.

Fully intelligent, multifunctional, high measurement performance, and strong environmental adaptability;

Simultaneous display of multiple parameters, including height, output current, time, and relay status;

2-channel 4-20mA transmission output, relay high and low alarm control output;

RS485, RS232 upload function, printing function (optional);

Capable of installing independent storage cards with data recording, storage, and export functions;

Multiple signal options;

Maintenance is very simple, just clean the sensor (optional self-cleaning probe, maintenance free);

Adopting multiple calibration methods to ensure measurement accuracy;

Chinese and English menus are optional (optional);

Self set password: Users can set or modify their own password to prevent unauthorized personnel from entering and causing misoperation.
